Sheet cutter Jagenberg synchro 300 - 1650 mm
Querschneider
Technische Daten:
Maschine:
Sheet cutter Jagenberg synchro 300 - 1650 mm
Artikel-Nr.:
6552
Hersteller:
Jagenberg
Typ:
Synchro 300 - 1650
Größe:
1600mm
Beschreibung:
Manufacturer: Jagenberg
Type: synchro 300 - 1650
Primary reels diameter: min. 430 mm - max. 1350 mm
Rells face width: min. 480 mm - max. 1600 mm
Core diameter: 150 mm
Sheet width: min 450 mm single sheet - min 320 mm double sheet - max. 1460 mm
Sheet length: min 450 mm - max 1600 mm
Loading cutting knife: 920 g/m²
Angular tolerance: 1mm up to 1600 mm sheet length
Sheeting tolerance: 1 mm up to 1000 mm sheet length
Grammage range: min. 80g/m² - max. 380g/m²
Max height of paper stacked: 1700 mm icluding pallet
Speed: max. 250 m/min
Potential running webs: 8
