Hauptbild Name Hersteller Typ Größe Kapazität

Paper converting / finishing line

Cerutti Laminator/Coater

  • Wet (waterbased) or dry Lamination (waterbased or solvent based)

  • Lens/holographic optima register system – Weko re-wetting system

  • Metpol/aluminium foil/transmet

  • Two gravure heads  - 1st head for the adhesive & 2nd head usually applies the lacquer if required (waterbased or solvent based)

  • Two rewinds – one for laminate and one for stripped film on transmet

  • 1240mm max substrate – board/paper

  • 1.5m max OD

  • 1.0m max OD topstrate – film/foil etc

Can use 76mm core on board unwind also (only laminator that can)

Drying Systems – Hot Oil Drying on both Cerutti Laminator/Coaters



Kroenert Laminator

  • Wet Lamination only (waterbased)

  • Metpol/foil – not currently transmet

  • Workhorse for drinks market

  • Roller coating (rubber & steel) for adhesive and gravure for lacquer

  • Clear lacquers only (not golds)

  • One rewind though has an additional in-house rewind added also

  • 1229mm max substrate – board/paper

  • 1800mm max OD

1.0m max OD topstrate – film/foil etc

SLITTERS

WICKELTECHNIK - Jumbo Slitter

  • Max slit width – 1250mm

  • Min slit width – 300mm

  • Board Thickness  Min 60 microns  Max 800 microns

  • Max reel OD – 1800mm

  • Max reel OD  - 1800mm

  • Slit width min. 500mm

  • Slit width  max. 1250mm

  • Lens/Holographic registration monitoring capability for reels

  • 152, 302 & 305mm cores sizes

  • Used for board mainly



Atlas Slitter

  • Max slit width – 1250

  • Min slit width – 300mm

  • Max reel OD – 1800mm

  • Max rewind dia – 1800mm

  • Core sizes 152, 302 & 305mm

  • Used for board mainly

  • Rewind min slit width 350mm

  • Rewind max slit width 1050 mm



WICKELTECHNIK Coiler (Bobbins)

  • Max slit width – 1250mm

Min slit width – 455mm

  • Max OD – 1800mm

  • Smaller cores sizes – 76,152  302 and 305mm

  • Min slit width – 65mm

  • Has film stripping capability – used for a lot of paper film stripping



Splitter

  • Widest slit width

  • Has film stripping capability – used for some paper film stripping

  • Used for slitting PET film also

  • Has corona treatment capability





Sheeters & Guillotine

SHM (Strachan Henshaw) - Sheeter

  • Max input width – 1170mm

  • Max reel input OD – 1800mm

  • Pallet height – 1700mm

  • Min and max sheet chop length – 550 to 1500mm

  • Min and max sheet widths – 250 to 1170mm



Guillotine Schneider

  • Max output sheet size of 1080 x 1250mm

Min trim 2mm

European manufacturers

Rollenschneider PSA 2200 mm

Arbeitsbreite: 2200 mm Durchlass / Ballenbreite 2200 mm

Abrollung: achslose Abrollung Originalrollenaufnahme von ca. Ø 800 mm vom Boden. Hülsenbreite von 800 mm – 2200 mm Öffnungsweite 2500 mm Originalrollen-∅: 1250 mm, max. Rollengewicht 2.000 kg

Originalrollenhülsen ∅: 76 mm (3“) / 152 mm (6“) l.W. für Pappe, Kunststoff, Stahl

Bahnregelung: Kantensteuerung Fa. E&L Ultrasensor auf Kante Verfahrweg +/- 100 mm

Materialausgleich: a) Tänzer pneumatisch geregelt b) zweiseitig verstellbare Leitwalze

PSA PaperSlit- AR 2200 2200 mm

Rollenschneider Nicely 1450 mm

Thickness of materials  0,075 mm - 0,6 mm

Weight loading capacity: Max 2000 kg

Material width: 500 mm - 1450 mm

Unwind core diameter: 76,2 / 152,4 mm paper core

Max rewind diameter: 600 mm

Rewind core diameter: 75,2 / 152,4 mm

Mechanical speed: 250 m/min

Nicely Taiwan 1450 mm 250 m/min

Umroller Goebel U 15

Gebrauchter Umroller Goebel U 15:

Arbeitsbreite: 3200mm

Abrolldurchmesser max.: 2000mm

Wickeldurchmesser max. 1250mm

Geschwindigkeit (je nach Materialqualität und Eignung) max.: 1200 m/min



Goebel U 15 3200 mm 1200 m/min

Goebel Rapid 1600 mm

Kleiner Goebel Rapid Rollenschneider mit achloser Abrollung

Goebel Rapid ca 1600 mm

Spout insertion machine made by Hesen

Technische Information:

Taschenformat: Breit 120 – 280 mm  Länge 180 – 325 mm
Auslauf: Pöppelmann Ø 10,5mm & Ø 17,5mm   Menshen Ø 10,5mm
Geschwindigkeit: bis zu 50 Beutel/min, abhängig von der Folienkombination
Folientypen: PET-O / Alu / PE    PET-O / PA-O / PE
                     PET-O/PE mit/ohne EVOH
                     PP-O/PE mit/ohne EVOH
                     PA-O / PE
                     PE-O / PE mit EVOH
Filmstärke: 80 – 280µ

Hensen Packaging Concept HPC SI 350 Bag format: Wide 120 – 280mm Length 180 – 325mm

Papiertütenmaschine Newlong 136T + 508TH

·With inline flat handle unit

·One ply bags

·Cutting length without handles:210- 480 mm

·Cutting length with handles: 210- 480 mm

·Bag length without handles: 135 – 435 mm

·Bag length with handles: 135 – 435 mm

·Bag width without handles: 150-320 mm

·Bag width with handles: 180-320 mm

·Bottom width (without handles): 55-165 mm

·Bottom width: 60-165 mm

·Machine speed: 200 bags/min. Real speed depends on operator , size of bags, thickness of paper , handles etc

·Paper width: 1000 mm

·Paper roll dia.: 1200 mm

·Bag width +bottom width: 240-485 mm

·Weight of web: 60 – 125 gsm

·With photocell

·Overall dimensions L 10850 mm x W 3500 mm x H 2500 mm

·Net weight 10,5 tons

·Voltage: 380V/50HZ

·Total power consumption: 11 kw

·Power consumption of drive motor: 5,5 kW

·The machine has had some updates like safety guards

Newlong 136T + 508 TH

Sheet cutter for pressboard

- Schneidwerk längs und quer für das Schneiden von Tafelpressspan

- Arbeitsbreite Längs ca. 2.300 mm

- Arbeitsbreite Quer ca. 4.400 mm

- ohne SPS Steuerung, Steuerung erfolgt über Lichtschranken, Pneumatik und Zeitrelais

- Schneidtechnologie: Schneidmesser

- stufenlose Positionierung der Messer entlang der Messerwalzen

- Eintauchtiefe der Messer variabel Einstellbar

- Originaldokumentation teilweise vorhanden

- Maße Schneidwerke, Zuführtisch, Umlenktisch, Abgabetisch: 11,0 x 7 m (L x B)

Central Adams

Tissue converting machinery - doubling machine - Embossing calander - small rewinder

Machinery to produce for example high grade table cloths rolls or sanitary requirements

Consisting of

- 4 lay tissue doubling machine

- Embossing calander

- Small rewinder for product rolls

Umroller Jagenberg

Slitter rewinder, pick up unwind stand, Shaft rewinding, width ca 1100 mm

Jagenberg ca 1100 mm 300 m/min
