Verkaufsliste

Angle: 30

Width: 4,6

Nut: 3,4

Height: 4,0

Length: 6,3

Angle: 25

Width: 4,0

Nut: 3,0

Height: 6,0

Length: 5,9

Link to manufacturer website with further details about this type of machine:

https://www.bematec.ch/en/products-bematec/product-bematec-claflins-111-222-333/

Technical details:
Infeed:  Automatic
Operation:  Electro-mechanical/pneumatic
Max. machine speed:  14 cycles/min.
Max. production speed:  13 cycles/min.
Roll infeed height:  770 mm
Pack exit height:  1150 mm
Weight:  5500 kg (approx)
Av. size change-over time:  35 min. (approx) 2 Operators
Av. size adjustment time:  20 min. (approx) 2 Operators
Roll change time:  5 minutes
Ambient conditions
• Temperature from +5 to +40°C
• Relative humidity Max. 70%

PNEUMATIC SYSTEM
Air pressure:  6 bar
Compressed air consumption Max.:  800 Nl/min

ELECTRICAL SYSTEM (STANDARD)
Installed power:  23.5 KVA
Standard voltage:  3x380/415/440 V (+/- 5%) + earth
Voltage variation:  +/- 5%
Frequency:  50/60 Hz
Neutral wire:  None
Electrical cabinet voltage:  220 V AC
PLC I/O card voltage
• Inputs/outputs 24 V DC
• Solenoid valve outputs 24 V DC
• Contactor outputs 24 V DC

PRODUCTS TO BE PACKED
Pack height (H) from 95 to 305 mm
Pack width (W) from 95 to 560 mm
Pack length (L1) from 190 to 560 mm

FINISHED PACKAGE DIMENSIONS
Pack width (W):  From 330 to 780 mm
Max.:  850 con H 250mm
Max.:  700 con H 345mm
Max.:  720 con H 400mm
Pack length:  (L) From 200 to 800 mm
Pack height:  (H) From 195 to 305 mm
400 mm (Optional)
