Neu eingetroffen

Hauptbild Name Hersteller Typ Größe Kapazität

Anlage zum Auflösen von nassfesten Ausschusspapieren

komplette Anlage bestehend aus:

- Aufsteigende Eindickschnecke

- Propfenschnecke

- Disperger

- Antriebsmotoren

- Steuerung

- Rahmen

- Laufstege

- Antriebe

- Steuerung



Cellwood Machinery KD 710 LC 70 t/day

Faltschachtelklebemaschine Jagenberg Diana 115 - 3


Faltschachtelklebemaschine 115-3
Wellenarten: von F- Welle bis E- Welle, stehende B-Welle nur mit geringer Laufleistung


Normale Faltschachtel:
Kaliber Karton und Welle: von 0,25 - 3 mm
Grammatur: von 200 - 900 g/m²
Einzug: 40 x 900 mm
Breite min. x max.: 145 x 1150 mm
Klebelasche: 5 - 40 mm
Maß von der Klebelasche bis zur 4-ten Rillung maximal 990 mm

Faltbodenfaltschachtel:
Kaliber: von 0,25 - 3 mm
Grammatur: von 250 - 900 g/m²
Einzug: 55 x 900 mm
Breite min. x max.: 190 x 1080 mm
Klebelasche: 10 - 40 mm
Maß von der Klebelasche ersten Rillung bis zur 4-ten Rillung maximal 990mm



Jagenberg Diana 115 -3

Die cutting machine WUPA PS 6.3

grey cardboard from                           600 - 1200 g/m²

Thickness:                                         from 0.15 - 6 mm



Grammage:                                       from 180 - 1200 g/m²

Minimum sheet size:                          590 x 700 mm

Sheet format, maximum:                  1015 x 1410 mm

Cutter-to-cutter:                                 995 x 1390 mm

Start of sheet to 1st cutter:                15 mm



            Wave types:                           F-wave

W-wave

E-wave

B-wave

C-wave

Double waves: FF-wave

FE-wave

FB-wave

EB-wave

WUPA PS 6.3

Presona Ballenpresse mit Beschickungsband, Staubabsaugung und Zyklon

Gebrauchte Papierpressanlage
Bestehend aus:
1 Ballenpresse
Hersteller: Presona
Typ LP 50 EH1
Pressleistung: 500 Kn
Ballengröße: 1100 x 720
Leistungsbedarf 22 KW

1 Aufsteigendes Zuführband
1 Staubbehälter
1 Zyklon

Presona Horizontal bale press LP 50 EH1 bale size 110 x 720

Bogenlaminiermaschine

For solid board or corrugated board with a thickness of 0.75 to 8 mm

Cover sheet: paper or solid board from 120 - 700 g/m²

Minimum format:                   Width: 500 mm

                                               Length: 500 mm

Maximum format:                  Width: 1650 mm

           Length: 1650 mm

Glue types:                             vinyl-containing cold glue or corn glue

Tolerance:                              +/- 0.5 mm with good material quality

Max. mech. speed:                3,500 sheets/hour (depending on material quality, sheet format)

             material quality, the sheet format and the operator)

Klett 165 - 165 Zero max 165 x 165 cm 3500 sheet per hour

Near to new channel dryer 0,8 m width

Manufacturer:            Ahlbrandt

Conveyor with:           0,8 m

Condition:                   very good

Heated by:                  Gas

Max temp:                  130 °C

 Consisting of:             4 drying modules from each 4m long.



2 of them are connected by a single conveyor belt and the 2

others modules have their own conveyor belt.



Each unit has its own 200 kW gas heater (could be easily re

build to other heating systems), 15 kW circulation fan and 7.5

kW extraction fan.



The conveyor belt has a width of 0.8 m and is driven by an au

tomatic belt alignment system.



Ahlbrandt Hot Air Dryer 0,8 m width

Paper bag machine Triumph 5A/SM

Type of bag: SOS bag with flat handle

Min.-Max. bag width: 220 - 450 mm
Min.-Max. cut off length: 120 - 650 mm
Min.-Max. bottom width: 90 - 220 mm
Handle unit: yes, flat handle
Max. side gussset: 180 mm
Max. number of cycles: 180 bags/min
Material: Paper 70 - 150 gsm
Max. unwind width: 1370 mm
Max. unwind reel diam.: 1200 mm
Photocell: yes

W&H Triumph 5A/SM

Guillotine Creuso - Loire B150

Creuso - Loire B 150 ELEC 150 cm

Sorting machine for labels Prati Jupiter TC400

Second hand sorting machine for labels

Prati Jupiter TC400

With AVT inspection system

Prati Jupiter TC400

Letterpress Codimag Viva 340

Letterpress semi rotary printing machine

4 colours

2 cutting units

Codimag Viva 340
